Size Range
Inlet port:2"-6" Outlet port:4"-16"
Pressure Rating
CLASS150-2500Lb
Temperature Range
-29 ℃~120 ℃(or specially engineered design)
This Multi-port fluid selector valve sequentially isolates one line for precise metering, while diverting the flow from all other lines to a common gathering outlet. It streamlines oil and gas well testing by eliminating the need for complex, multi-valve manifolds.
Multi-port Selector Valves
Specifications
Size Range
Inlet port:2"-6" Outlet port:4"-16"
Pressure Rating
CLASS150-2500Lb
Body Materials
A105、304、316、Duplex Stainless Steel etc.
Temperature Range
-29 ℃~120 ℃
Connection methods
threaded connection (NPT/GB), flange connection (ANSI/GB), welded connection
Design standards
ASME B16.34、API598、ANSI FCI70-2
Test standard
API598、ANSI FCI70-2
