Size Range
Inlet port: 2"-6" Outlet port: 4"-16"
Pressure Rating
Class 150 up to Class 2500
Temperature Range
-29 ℃~120 ℃(or specially engineered design)
Our Multiport Flow Selector Measurement Skid isolates one line sequentially for precise metering, while diverting all other fluid streams to a common gathering outlet. By replacing complex multi-valve manifold systems, it greatly simplifies oil and gas well testing operations.
Multiport Flow Selector Measurement Skid
Subscribe to
the sample
Subscribe to
the sample
Subscribe
By subscribing, you accept the
privacy policy and the processing of personal data
Specifications
Size Range
Inlet port: 2"-6" Outlet port: 4"-16"
Pressure Rating
Class 150 up to Class 2500
Body Materials
A105、304、316、Duplex Stainless Steel etc.
Trim Materials
304, 316、Duplex Stainless Steel etc.
Body Style
Two Piece Bolted Wafer
Gate Materials
304, 316, 317 Stainless Steel, SAF 2507, SAF 2205, 17-4PH, Hastelloy® C, Monel®
Seat Material Temperature Range
"Natural Rubber -60°F to 165°F (-51°C to 74°C)
EPDM -65°F to 248°F (-54°C to 120°C)"
Design Standard
ASME B16.34、API598、ANSI FCI70-2
Wiper Materials
EPDM
Testing Standard
API598、ANSI FCI70-2
Certifications
ATEX, CRN, PED, PE(S)R
Face to Face
Manufacturer Standard
Actuator Options
Electric,Electric-Hydraulic
Applications
water、oil、gas
Qualification
Type test certificate for special equipment
Type test certificate for special equipment
API 607
API 607
Type test certificate for special equipment
Type test certificate for special equipment
API 607
API 607
API 607
API 607
